Challenge 2 -Task 1In deploying a new application, a cloud customer needs to reflect different...

To create a Custom Security Zone Recipe named IAD-SP-PBT-CSP-01 that allows the provisioning of compute instances in a public subnet, we will follow the steps outlined in the Oracle Cloud Infrastructure (OCI) Security Zones documentation. These steps are based on verified procedures from the OCI Security Zone Guide and related resources.

Step-by-Step Solution for Task 1: Create a Custom Security Zone Recipe

Log in to the OCI Console:

Use your OCI credentials to log in to the OCI Console (https://console.us-ashburn-1.oraclecloud.com ).

Ensure you have access to the assigned compartment provided in the tenancy.

Navigate to Security Zones:

From the OCI Console, go to the navigation menu (hamburger icon) on the top left.

UnderGovernance and Administration, selectSecurity Zones.

Create a New Security Zone Recipe:

In the Security Zones dashboard, click on theRecipestab.

Click theCreate Recipebutton.

Configure the Recipe Details:

Name:Enter IAD-SP-PBT-CSP-01.

Description:(Optional) Add a description, e.g., "Custom recipe to allow compute instances in public subnet."

Leave theCompartmentas the assigned compartment provided.

Define the Security Zone Policy:

In the policy editor, start with a base policy. Since the Maximum Security Zone recipe restricts public subnet usage, you need to customize it.

Add the following policy statement to allow compute instances in a public subnet:

Allow service compute to use virtual-network-family in compartment where ALL {

target.resource.type = 'Instance',

target.vcn.cidr_block = '10.0.0.0/16',

target.subnet.cidr_block = '10.0.10.0/24'

}

Replace with the name of your assigned compartment.

This policy allows the Compute service to provision instances in the public subnet (10.0.10.0/24) within the VCN (10.0.0.0/16).

Adjust Restrictions:

Ensure the recipe does not inherit the Maximum Security Zone recipe's default restrictions that block public subnet usage. Explicitly allow the public subnet by including the subnet CIDR block (10.0.10.0/24) in the policy.

Remove or modify any conflicting default rules that prohibit public subnet usage (e.g., rules blocking internet access or public IP assignment).

Save the Recipe:

ClickCreateto save the custom security zone recipe.

Once created, note theOCIDof the recipe from the recipe details page. The OCID will be a unique identifier starting with ocid1.securityzonerecipe.

Verify the Recipe:

Go to theRecipestab and locate IAD-SP-PBT-CSP-01.

Ensure the policy reflects the allowance for compute instances in the public subnet by reviewing the policy statement.

OCID of the Created Custom Security Zone Recipe

The exact OCID will be generated upon creation (e.g., ocid1.securityzonerecipe.oc1..unique_string). Please enter the OCID displayed in the OCI Console after completing Step 7.

Notes

Ensure IAM policies are correctly configured to grant you permissions to create and manage security zone recipes in the compartment.

The policy assumes the public subnet CIDR (10.0.10.0/24) matches the diagram. Adjust if the actual subnet CIDR differs.

Test the recipe by associating it with a security zone and attempting to launch a compute instance to confirm compliance.
