Refer to the exhibit.

Vendor: Cisco
Product: 300-510
Update on: Jul 27, 2025
Questions: 214

Cisco 300-510 Question Answer

The service provider deployed segment routing in its core P2 is connected to P3 and P4 via a point-to-multipoint link as shown The service provider provides connectivity for a large enterprise with three main offices in different geographic regions Each office is connected via one of the three PEs The enterprise wants to implement multicast traffic across the service provider to stream mission-critical applications between sites The applications will be sourced from a server connected to the network through PE2 Which action must the network-engineering team take so that multicast traffic will flow between the enterprise sites over the point-to-multipoint link?

Implement RSVP to reserve bandwidth on the link between PE2 and P2

Implement PIM-DM to flood multicast traffic from the enterprise into the service provider core

Implement MLDP to allow multicast traffic to flow within the single AS

Implement SR Tree-SID to build a multicast replication tree over the point-to-multipoint link
