Identify the portion of the connector that carries the signal.

The tip portion of the connector.

This is a 1/4-inch TS (Tip-Sleeve) connector, commonly known as an unbalanced mono plug. For these connectors, the tip is the portion responsible for carrying the signal, while the sleeve serves as the ground or return path. In audio applications, TS connectors are typically used for unbalanced signals, such as instrument cables for guitars.

The tip of the connector is at the very end, identifiable by the small section separated by an insulating ring. This section is where the signal travels.

The sleeve is the long metal section that connects to the ground.

CTS Technology Specialist Reference

The CTS materials on audio connectors detail how TS connectors carry signals, with the tip designated for signal and the sleeve for ground. Recognizing the signal-carrying part is crucial for proper AV connections and troubleshooting.
