As shown in the figure, R1 imports the direct route 10.

Let ' s break it down step by step based on Huawei ' s routing protocol behavior:

R1 imports the direct route 10.1.1.0/24 into OSPF .

This route is advertised by R1 to R2 and R3 via OSPF .

Both R2 and R3 are running IS-IS , and bidirectional route redistribution is configured between OSPF and IS-IS.

R2 and R3 both re-advertise the OSPF-learned route into IS-IS and then potentially re-learn it back from the IS-IS domain, causing redistribution loops unless properly controlled.

Now, the question focuses on R3’s routing table :

R3 already learns the route directly via OSPF from R1.

It also learns the same route again via IS-IS from R2 (looped back due to bidirectional redistribution).

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“OSPF ASE routes are assigned a default preference of 150. If a route is redistributed from another protocol (like IS-IS) into OSPF, and then re-learned, it is considered an ASE route.” (Chapter: OSPF Advanced Features – Section: Route Redistribution Behavior)
