Refer to the exhibits.

Understanding API-led Connectivity Layers:

In MuleSoft’s API-led connectivity approach, APIs are categorized into three layers:

Experience Layer: This layer is responsible for providing data to the end-user applications and is often customized to meet the needs of different user interfaces.

Process Layer: This layer is used to orchestrate and combine data from multiple System APIs. It acts as a mediator and business logic layer without directly interacting with the backend systems.

System Layer: This layer provides direct access to the backend systems (e.g., databases, ERPs) and is usually focused on exposing atomic data operations.

Evaluating the Architectural Constraints:

Option A: Always using a strict tiered approach by creating exactly one API per layer is not necessarily an architectural constraint of API-led connectivity. While a layered approach is recommended, it is common to have multiple APIs in each layer as needed for different functionalities.

Option B (Correct Answer): In API-led connectivity, Process APIs are generally responsible for orchestrating calls to System APIs and should not call other Process APIs. This maintains a clear separation of concerns, ensuring that Process APIs aggregate data from System APIs only and provide it to Experience APIs.

Option C: System APIs are generally designed to provide only the necessary data to meet current business requirements. Allowing them to return extra data that is not needed by Process or Experience APIs is not a best practice, as it can lead to inefficiencies.

Option D: Customizations specific to end-user applications are typically handled at the Experience Layer rather than the Process Layer, as the Experience Layer is intended to tailor the data to fit the needs of each specific client or front-end application.

Conclusion:

Option B is the correct answer as it aligns with the API-led connectivity principles. In this architectural style, Process APIs should orchestrate System APIs but should avoid interacting with other Process APIs to keep a clear separation of responsibilities across the layers.

For additional details, refer to MuleSoft documentation on API-led connectivity best practices, particularly around the roles of each layer in API orchestration and data handling.
